User Guide for Flashing and Tuning the SpeedyBee F405 V3 Stack with Betaflight

Version 0.2

Introduction

Checklist

Wiring diagram

Glossary

Flash FC

Flash ESC

Final setup check

To proceed, REMOVE the propellers from your UAV and connect the VTX.

Appendix #1. Useful video

Appendix #2. Flashing Betaflight firmware in DFU mode

Introduction

In this manual, the issue of fine-tuning the flight controller and ESC is not considered. This is due to the fact that each UAV operator has his own vision on this issue. And nowadays, the UAV flies well on standard settings. Links to instructions where fine-tuning Betaflight is considered in detail are provided at the end of this manual at section “Useful video”. You can view them if you're interested, but you don't have to.

Checklist

1. Check that your hardware is the same as described at section “Hardware”.
2. Check that all connections correspond to the scheme given in the "Wiring diagram" section.
3. Check for a short circuit on the power lines with a multimeter.
4. Check that the antennas are connected to the RC and VTX.
